EQUIPMENT AT THE MICROSCOPY CENTER


Scanning Transmission Electron Microscope

  • FEI-Philips scanning transmission electron microscope, Model Tecnai T12T/STEM
  • Located in Room GDYR-108
  • Accelerating voltage of 20-120 kV
  • Line resolution 2 Angstrom and point resolution 3.4 Angstrom
  • Magnification range of 35-600,000X
  • The specimen can be tilted in two directions, around the x-axis up to ±70 degrees and around the y-axis up to ±30 degrees
  • Photomicrographs can be taken on film or recorded digitally
  • It is used in electron energy-loss spectroscopy and imaging studies

Field Emission Scanning Electron Microscope

  • Model JEOL-7401 Japan Electron Optics Laboratory (JEOL)
  • Located in room GDYR-109
  • Accelerating voltage of 0.5-35 kV
  • Magnification range of 15-600,000
  • Genesis X-ray microanalysis systems with EDS detector
  • The specimen can be tilted up to 90 degrees in one direction
  • The microscope is interfaced with a scanner-computer system that provides digital electron microscope images to be printed on paper

Transmission Electron Microscope (TEM)

  • Vender: JEOL
  • Model: JSM-1230
  • 120KV illumination system
  • Single-Tilt/Rotation stage
  • Maximum magnification of 500K
  • Maximum resolution of ~1nm
  • Wide range of diffraction techniques
  • Genesis X-ray microanalysis systems with EDS detector
  • Bottom Mount CCD camera with 2048X2048 pixels

Polarized Light Microscope

  • Model Labophot-Pol Nikon
  • Located in room GDYR-105
  • Can be used to obtain photomicrographs using positive/negative
  • Polaroid or 35mm films

Optical Microscope

  • Olympus BX-51
  • Equipped with Mettler Hot Stage
  • Located in room GDYR-105
  • Can be used to obtain high resolution digital images and video

Vacuum Evaporator

  • Model JEE-4C JEOL
  • Located in room GDYR-105
  • Used in the preparation of specimens for transmission electron microscopy by casting carbon and metal films under high vacuum

High Vacuum Evaporator

  • Model DV-502A Denton
  • Located in room GDYR-105
  • Used for evaporation and casting of films of carbon, metals, and dielectrics

Ultramicrotome

  • RMC Model CRX-PC
  • Located in room GDYR-109
  • Used for the preparation of ultrathin sections of polymers for transmission electron microscopy and for polishing the surface of polymer samples for scanning electron microscopy

Sputter Coater

  • SPI
  • Located in room GDYR-105
  • Used to coat specimens with gold, gold/palladium or other metal before examining the specimens in the scanning electron microscope.

Photographic Darkroom

  • Located in room GDYR-106
  • Used for developing and printing of optical and electron micrographs


EQUIPMENT AT THE NUCLEAR MAGNETIC RESONANCE CENTER


Varian NMRS 500 (5 ch)

  • This is a Research grade 5 channel instrument equipped for double and triple resonance experiments in both solids and liquids. It includes a suite of probes to do essentially every useful permutation of triple resonance experiments, including 1H/13C/X (where X covers essentially the entire range of nuclear resonance frequencies). The instrument was purchased to perform diffusion experiments with high gradient strengths (120 Gauss/cm), and very high temperature (up to 250 deg. C) solution and solids experiments.
  • Instrument rates for UA users can be found on the Magnet Intranet Rates page. NMRS 500-02 GDYR 103a
  • The nature and variety of experiments which are performed on this instrument require that time be scheduled at least one (1) to two (2) weeks in advance. Contact lab personnel by Noon on Wednesdays to request instrument time for the following 2 weeks.

Varian NMRS 500

  • This is a Research grade 2 channel instrument for H/X double resonance experiments. It is equipped with a robotic sample changer, auto-tune and auto-shim capabilities for continuous unattended instrument optimization and operation. This instruments configuration will alternate between robotic operation of 10- and 5-mm dual broadband probes (based on demand).
  • For access to this instrument, please contact Dr. Dudipala for training and checkout. Once you have been checked out to operate this instrument, time can be reserved via the Intranet Scheduling page.

Varian MERCURY 300

  • This NMR instrument is a 300 MHz spectrometers equipped to observe 1H/19F and 13C/31P. In addition to routine 1-D 1H and 13C spectra, homo- and heteronuclear decoupling, APT, DEPT, COSY, HETCOR (Heteronuclear shift correlation), homonuclear-2DJ, NOE Difference and saturation experiments etc., can be performed.
  • This is intended to be walk up instruments for undergraduate and graduate student research. Only people who have been checked out by lab personnel are allowed to use the instrument.
  • These instruments are intended for routine walk-up access, however up to 30 minute time slots may be reserved between the hours of 8:00 AM and 5:00 PM.; two hour time slots can be reserved from 5:00 P.M. to 10:00 P.M., and up to 10 hours can be reserved between 10:00 P.M. and 8:00 AM.; Signup is via a reservation system accessible via the Magnet Intranet page.

The following five instruments are available in the chemistry department:

  • Inova-750 solids and liquids NMR spectrometer
  • Inova-400 solution NMR spectrometer
  • Gemini-300 solution NMR spectrometer
  • Inova-200 solids NMR spectrometer
  • CMC-200 triple resonance solids NMR spectrometer

EQUIPMENT AT THE MOLECULAR CHARACTERIZATION LABORATORY


GPC - Room Temperature Instrument

Typically running with THF mobile phase with two choices of detector arrangements:

  • A. Viscotek Triple Detector operation, TriSEC
    • Waters Differential Refractometer, Model 410
    • Viscotek Viscometer, Model 100
    • Wyatt Dawn EOS light scattering@90º angle
    • The PC based data system uses a Viscotek 3-detector interface and TriSEC software. Data analysis can also accommodate both universal calibration (2 detectors) and conventional calibration (1 detector) but these require that current column calibration data be on file.
  • B. Wyatt Multi-Angle Laser Light Scattering, MALLS
    • Waters Differential Refractometer, Model 410
    • Wyatt Dawn EOS light scattering employing 15 angles
    • The PC based data system uses Wyatt ASTRA software.
  • Note: both Viscotek and Wyatt claim absolute results for their respective approaches to molecular weight measurement.

Brookhaven Research Goniometer and Laser Light Scattering System

  • Supports both static and dynamic light scattering measurements (Dynamic Light Scattering, DLS also referred to as Photon Correlation Spectroscopy (PCS) or Quasi-elastic Light Scattering (QELS).

Wyatt Dawn EOS Batch Mode Light Scattering

  • Weight average molecular weight determination by light scattering utilizing the Dawn EOS multi-angle instrument in batch mode in lieu of chromatography.
  • Batch Mode: the flow cell is removed and samples in solution in scintillation vials are measured directly.
  • Micro-Batch Mode: samples in solution are pumped through the flow cell.


Hewlett Packard Model 8453 UV/VIS Spectrophotometer

  • Wavelength range 190-1100nm

Digilab Excalibur FTS 3000 series FTIR Spectrometer with Win-IR Pro Software

Bruker TENSOR 27 FTIR Spectrometer with OPUS software

Rame-Hart Model 500 Advanced Goniometer with DROPimage Software

  • Measurement of interfacial tension and contact angle by image analysis.

Malvern Instruments Zetasizer Nano-ZS90 and MPT-2 Titrator

  • Particle size measurement and zeta potential.

TA Instruments Model Q2000 DSC

  • With LNCS liquid nitrogen cooling accessory for use down to –180˚C.

TA Instruments Model Q500 TGA

Knauer Membrane Osmometer

Knauer Vapor Pressure Osmometer

Wescan Recording Osmometer

Mettler Toledo AX105 Delta Range Balance

  • Max 31/110 g, d=0.01mg/0.1 mg.

EQUIPMENT AT THE POLYMER SCIENCE MACHINE SHOP


Clausing Colchester 15" lathe

Clausing 13" lathe

Horizontal cut off saw



Vertical cut off saw

Oxygen and Acetylene torches



Bridgeport Milling Machine

Haas Super Mini CNC Mill

Lincoln Electric Precision TIG/Stick 275 Amp Welder

Vertical Band Saw

Wide selection of Starrett Quality Control Precision Measuring tools (i.e., inside and outside micrometers, digital readout caliper verniers, height gages, etc.).
