VPN Setup


Windows 7

For Windows 7 use the Cisco VPN Client


Windows 10

The Cisco VPN client does not work in Windows 10. You can use a VPN client made by ShrewSoft instead.

Once installed, you can find the software as the “VPN Access Manger” under “ShrewSoft VPN Client” in the Start menu if a shortcut was not created on the desktop during install. Open the software and click the Add button.

- Fill out the various tabs as follows (PDF) or import this file into ShrewSoft–



General: Add host name – vpn.uakron.edu

general_ssvpn



Client: No change

client_ssvpn



Name Resolution: No Change

nameResolution_ssvpn



Authentication

Local Identity Tab: Change

Authentication Method to “Mutual PSK + XAuth”
Identification Type to “Key Identifier”
Key ID String to “ Zipnet”  (must use capital Z)

authentication1_ssvpn



Remote Identity Tab: No Change

authentication2_ssvpn



 Credentials: Change

Pre Shared Key to “zippy”

authentication3_ssvpn



 Phase 1, Phase 2, Policy: No Change

phase1_ssvpn
phase2_ssvpn
policy_ssvpn


Click Save and give the connection a name. Double click the connection and enter your uanet credentials to login. You can disconnect from the software window or by right-clicking the ShrewSoft icon in the system tray.
